Kubewekend πŸ‘¨β€πŸš€πŸš€β˜οΈπŸŒ•

[!NOTE]

Learn how to setup the fully kubernetes cluster inside your local environment


Table of Contents

Usage

[!NOTE]

Supported K8s Distribution with Kubewekend Readmore to select what distribution for yourself

  1. SUSE - When to Use K3s and RKE2
  2. Dev.to - The Definitive Guide to Lightweight Kubernetes: KIND, Minikube, MicroK8s, K3s, Vcluster, k0s, and RKE2 Compared
  3. Plural - K3s Alternatives: A Guide for Platform Teams

[!WARNING]

Disclaimer: Kubewekend is designed to run the scripts on an Ansible controller and deploy clusters to target hosts: VM (e.g: Vagrant + VirtualBox) or VPS Remote over SSH. Using your current machine as the target (Local) is only supported for Kind, because it runs inside Docker, and it is still not recommended on your main machine: with networkForwarding enabled, Kind creates socat-netforward-port-80/443 systemd services that bind host port 80/443, so remember to run kind destroy (or disable the services) when you finish. K3s and RKE2 are not supported on Local: they install system services, write /etc/rancher and change host networking, and can break your local system.

Kubewekend Cluster Distribution Local VM VPS Remote
Kind (K8s in Docker) βœ… βœ… βœ…
K3s Standalone ❌ βœ… βœ…
K3s High Availability (HA) ❌ βœ… βœ…
RKE2 Standalone ❌ βœ… βœ…
RKE2 High Availability (HA) ❌ βœ… βœ…

Find more another distribution: k0s, k3d, …

Requirements tools

Tool Required Purpose
VirtualBox Yes* VM provider
Vagrant Yes* VM provisioning
Ansible Yes Cluster orchestration
kubectl Yes Kubernetes CLI
Helm Yes Chart management
Docker Optional Required for Kind clusters
kind Optional Kind binary (also installed by playbook)

* Vagrant + VirtualBox are required only for local VM workflows. For remote VPS targets, only Ansible + SSH are needed.

Node resources

Size the VM / VPS before provisioning, a node with too little memory fails during bootstrap or gets killed (Error 137).

Node Distribution Minimum Recommended
Master (control-plane) RKE2 2 CPU, 2 GB RAM (lower will fail) 2 CPU, 3 GB RAM
Master (control-plane) K3s 1 CPU, 1 GB RAM 2 CPU, 2 GB RAM
Master (control-plane) Kind 1 CPU, 1 GB RAM 2 CPU, 2 GB RAM
Worker K3s / RKE2 1 CPU, 1 GB RAM 1 GB RAM or more

[!NOTE]

The Vagrantfile defaults to 2 CPU / 3 GB RAM for master VMs and 1 CPU / 1 GB RAM for worker VMs. Installing utilities (monitoring, GitOps, security, …) needs more resources, so raise config.memory / config.cpus for those workflows.

Kubewekend CLI (setup.sh)

[!TIP]

All cluster operations are unified under a single CLI. Run it from the project root β€” no need to invoke ansible-playbook or vagrant directly.

# Show all available commands
./scripts/setup.sh help

# Check prerequisites
./scripts/setup.sh env check

# Show subcommand help
./scripts/setup.sh <command> help
Command Purpose
env Check tools, initialise .env
vagrant VM lifecycle β€” up, halt, destroy, ssh
inventory Generate/inspect Ansible inventory, set remote VPS
kind Kind cluster β€” setup, destroy, utilities
k3s K3s cluster β€” standalone, HA, destroy, utilities
rke2 RKE2 cluster β€” standalone, HA, destroy, utilities
network VirtualBox NAT forwarding (hook-up / return)
config View / edit master.yaml and worker.yaml
status Project-wide status dashboard
quickstart Guided end-to-end workflows

See scripts/README.md for the full CLI reference.


Step by step

Setup Host with Vagrant

[!NOTE]

Read more at Kubewekend Session 1: Build up your host with Vagrant

  1. Position yourself at the project root.
  2. Bring up your VMs with the CLI:
# Provision only the master node
./scripts/setup.sh vagrant up k8s-master-machine

# Provision master + one worker (K3s / RKE2 standalone / Kind)
./scripts/setup.sh vagrant up k8s-master-machine k8s-worker-machine-1

# Provision master + multiple workers (K3s / RKE2 HA)
./scripts/setup.sh vagrant up k8s-master-machine k8s-worker-machine-1 k8s-worker-machine-2

[!NOTE]

You can also use vagrant directly with --provider=virtualbox. The CLI wraps it for convenience and ensures you stay in the project root.

Ansible Inventory β€” hosts File

[!IMPORTANT]

The inventory file at ansible/inventories/hosts is split into two sections. Make sure the right section is populated before running a playbook.

Section Group Used by
SECTION 1: Standalone standalone-masters, standalone-workers kind-playbook.yaml, k3s-playbook.yaml, rke2-playbook.yaml
SECTION 2: HA ha_master_init, ha_master_join, ha_worker k3s-ha-playbook.yaml, rke2-ha-playbook.yaml

Generate the inventory automatically from running Vagrant VMs:

./scripts/setup.sh inventory generate

# Or ping all known hosts to verify connectivity
./scripts/setup.sh inventory ping

# For a remote (non-Vagrant) VPS target
./scripts/setup.sh inventory set-remote

Setup K8s Cluster and Utilities Features

[!NOTE]

After the upgrade 12/2025 and 01/2026, Ansible Playbooks are already rebuilt for multiple concepts which allow you configure a lots of stuff with your Kind, K3s or RKE2 cluster to test and experiment K8s features

For more information, you can see what are implementing via table below

Kind (kind-playbook.yaml)

Name of Task Description Tags State
Install Common Kubewekend Tools Install common libraries, kind and dependencies for your host install_common βœ…
Setup Kind Cluster Create Kind Cluster with mounting kind-config template to ansible host setup_kind βœ…
Setup Kind Network (CNI) Setup network for Kind Cluster when disableDefaultCNI: true (Options: Calico, Flannel, Cilium) setup_kind βœ…
Setup Load Balancer for Kind cluster Setup Load Balancer for external LoadBalancer-type services (Options: metallb, cloud-provider-kind, cilium-ipam-lb) setup_kind βœ…
Setup Ingress Controller for Kind cluster Setup Ingress Controller (Options: NGINX, Traefik, Cilium, Kong) setup_kind βœ…
Setup GatewayAPI for Kind cluster Setup Gateway API (Options: Kong, Cilium, Traefik) setup_kind βœ…
Setup Network Forwarding for port 80/443 from host to Kind cluster Forward host ports 80/443 into Kind cluster via socat setup_kind βœ…
Remove Kind cluster Remove the Kind cluster and related components remove_kind βœ…

K3s (k3s-playbook.yaml Β· k3s-ha-playbook.yaml)

Name of Task Description Tags State
Install Common K3s Node Packages Install common libraries and dependencies on the target node install_common βœ…
Setup K3s Standalone (master or worker) Deploy K3s server (master) or agent (worker) β€” one node at a time via --host setup_k3s βœ…
Setup K3s High Availability (HA) Cluster Bootstrap etcd init node, join additional control-plane nodes, and attach agents setup_k3s βœ…
Configure CNI (Flannel / Calico / Cilium) Apply CNI manifests post-install based on k3sCluster.cni.type setup_k3s βœ…
Setup Load Balancer (ServiceLB / MetalLB) Deploy load balancer and configure IP pool from k3sCluster.loadBalancer setup_k3s βœ…
Setup Ingress + Dashboard + Support API Gateway (Only Traefik) Deploy ingress controller and optional dashboard from k3sCluster.ingress setup_k3s βœ…
Remove K3s node Uninstall K3s from all inventory nodes (server or agent) remove_k3s βœ…

RKE2 (rke2-playbook.yaml Β· rke2-ha-playbook.yaml)

Name of Task Description Tags State
Install Common RKE2 Node Packages Install common libraries and dependencies on the target node install_common βœ…
Setup RKE2 Standalone (master or worker) Deploy RKE2 server (master) or agent (worker) β€” one node at a time via --host setup_rke2 βœ…
Setup RKE2 High Availability (HA) Cluster Bootstrap init server, join additional control-plane nodes (embedded etcd or external PostgreSQL), and attach agents setup_rke2 βœ…
Configure CNI (Canal / Flannel / Calico / Cilium) Set cni in RKE2 config (+ HelmChartConfig for Flannel) based on rke2Cluster.cni.type setup_rke2 βœ…
Setup Load Balancer (ServiceLB / MetalLB) Enable the built-in ServiceLB, or deploy MetalLB with the IP pool from rke2Cluster.loadBalancer setup_rke2 βœ…
Setup Ingress (Traefik / Ingress-Nginx) Pick bundled ingress controller and customize it via HelmChartConfig from rke2Cluster.ingress.config setup_rke2 βœ…
Remove RKE2 node Uninstall RKE2 from all inventory nodes (server or agent) with rke2-uninstall.sh remove_rke2 βœ…

Utilities (k8s-utilities-playbook.yaml)

Name of Task Description Tags State
Ingress test deployment inside the cluster Deploy a sample workload to validate Ingress routing ingress_test βœ…
API Gateway test deployment inside the cluster Deploy a sample workload to validate API Gateway routing apigateway_test βœ…
Setup cert-manager for the cluster Install cert-manager for TLS certificate management certmanager βœ…
Setup Dashboard for the cluster Install a Kubernetes dashboard (type configured in utilities: kubernetes-dashboard, headlamp, rancher) dashboard βœ…
Setup Storage for the cluster Install Longhorn distributed block storage with optional iSCSI and NFS support storage βœ…
Setup Secret Management for the cluster Install Vault or OpenBao with optional auto-unseal, Vault Operator, and unseal key persistence secret_management βœ…
Setup K8s Extensions for the cluster Install Reflector, Reloader, and External Secrets Operator k8s_extensions βœ…
Setup GitOps for the cluster Install ArgoCD (with Image Updater + Extensions) or Flux (with Weave GitOps UI) and optional Kargo promotion engine gitops βœ…
Setup Security for the cluster Install policy engine (Kyverno or OPA Gatekeeper) and identity provider (Dex) for OIDC/OAuth2 authentication security βœ…
Setup Internal Developer Portal (IDP) for the cluster Install Backstage developer portal for application catalogue and self-service workflows idp βœ…
Setup Monitoring for the cluster Install the full LGTM observability stack: kube-prometheus-stack (Prometheus + Grafana), Alloy APM collector, Loki, Tempo, and Pyroscope monitoring βœ…
Setup Service Mesh for the cluster Install Istio service mesh for advanced traffic management, mTLS, and observability service_mesh βœ…

[!IMPORTANT]

Before running any playbook, review and adjust the cluster configuration file at ansible/inventories/host_vars/master.yaml. Use the CLI to inspect it without opening a text editor:

# Interactive table summary
./scripts/setup.sh config show

# Full raw YAML
./scripts/setup.sh config show --raw

# Open in $EDITOR
./scripts/setup.sh config edit

Kind cluster (all-in-one):

# Install common tools + create cluster
./scripts/setup.sh kind setup

# Add utilities after the cluster is up
./scripts/setup.sh kind utils certmanager ingress_test dashboard

# Tear down
./scripts/setup.sh kind destroy

K3s standalone (separate master / worker calls):

# Master first
./scripts/setup.sh k3s setup --host k8s-master-machine

# Then each worker
./scripts/setup.sh k3s setup --host k8s-worker-machine-1

# Add utilities
./scripts/setup.sh k3s utils certmanager gitops

# Tear down
./scripts/setup.sh k3s destroy

K3s HA cluster (HA section in hosts must be populated):

# Enable HA in master.yaml first
./scripts/setup.sh config edit

# Bootstrap all HA nodes at once
./scripts/setup.sh k3s ha-setup

RKE2 standalone (separate master / worker calls, same flow as K3s):

# Master first (RKE2 takes a few minutes to bootstrap)
./scripts/setup.sh rke2 setup --host k8s-master-machine

# Then each worker
./scripts/setup.sh rke2 setup --host k8s-worker-machine-1

# Add utilities
./scripts/setup.sh rke2 utils certmanager gitops

# Tear down
./scripts/setup.sh rke2 destroy

RKE2 HA cluster (HA section in hosts must be populated):

# Review rke2Cluster.highAvailability in master.yaml first
./scripts/setup.sh config edit

# Bootstrap all HA nodes at once
./scripts/setup.sh rke2 ha-setup

[!NOTE]

RKE2 serves its kubeconfig at /etc/rancher/rke2/rke2.yaml (copied to ~/.kube/config of the SSH user on the master). Replace 127.0.0.1 with the master IP when using it from outside. Traefik/Ingress-Nginx hostPorts are moved to 8000/8443 by default to avoid clashing with ServiceLB.

[!TIP]

Prefer the --dry-run flag to preview the exact ansible-playbook command that will be executed before committing:

./scripts/setup.sh k3s setup --host k8s-master-machine --dry-run

LGTM Stack β€” Continuous Monitoring, Logging & Profiling Example

[!NOTE]

The examples/lgtm-testing/ directory contains a full-stack demo application designed to showcase and stress-test the LGTM observability stack (Loki Β· Grafana Β· Tempo Β· Prometheus) combined with Pyroscope for continuous profiling. It is the recommended starting point for validating your monitoring setup after running the monitoring utility tag.

Architecture

Component Role
Frontend β€” Nginx + HTML dashboard Trigger test scenarios via UI
Backend β€” FastAPI + OpenTelemetry SDK Generates traces, structured logs, and custom metrics
PostgreSQL Persistence layer β€” produces DB span attributes
Pyroscope agent Continuous CPU/memory flamegraph profiling
Alloy DaemonSet collector β€” receives OTLP gRPC from app, routes to Tempo / Loki / Prometheus
Grafana Unified dashboard β€” correlate Traces ↔ Logs ↔ Profiles

Option 1 β€” Docker Compose (local, no cluster required)

cd examples/lgtm-testing
docker compose up -d --build
open http://localhost:3000   # frontend dashboard
open http://localhost:8000/docs  # FastAPI Swagger UI

Option 2 β€” Deploy into a running Kubernetes cluster

# Build and push images (or use a local registry for kind)
docker build -t lgtm-testing-backend:latest ./examples/lgtm-testing/backend
docker build -t lgtm-testing-frontend:latest ./examples/lgtm-testing/frontend

# Apply manifests
kubectl apply -f examples/lgtm-testing/k8s/namespace.yaml
kubectl apply -f examples/lgtm-testing/k8s/postgres.yaml
kubectl apply -f examples/lgtm-testing/k8s/backend.yaml
kubectl apply -f examples/lgtm-testing/k8s/frontend.yaml

# Wait for readiness
kubectl -n lgtm-testing wait --for=condition=ready pod \
  -l app.kubernetes.io/part-of=lgtm-testing --timeout=120s

Test scenarios included

Scenario Endpoint What to verify in Grafana
Normal CRUD (traces) GET/POST /api/todos/ Tempo: clean span waterfall; Loki: logs with trace_id
Auth failures POST /api/auth/login with bad creds Tempo: red error spans; Prometheus: auth_attempts_total
N+1 slow report GET /api/bottleneck/slow-report Tempo: many small DB spans; Loki: duration_ms warnings
CPU-intensive profiling GET /api/bottleneck/cpu-intensive Pyroscope: hashlib.sha256 + _fibonacci hotspots in flamegraph

Seed test data

curl -X POST http://localhost:8000/api/seed/

[!TIP]

Before deploying on Kubernetes, make sure the monitoring utility is already set up so Grafana, Loki, Tempo, and Pyroscope are available to receive telemetry data:

./scripts/setup.sh kind utils monitoring
# or
./scripts/setup.sh k3s utils monitoring

See examples/lgtm-testing/README.md for the full architecture diagram, custom metric reference, and Grafana exploration guide.


Helm Chart

For install helm-charts from kubewekend, you can use command

helm repo add kubewekend https://kubewekend.xeusnguyen.xyz

Troubleshoot

  1. Error when setup virtualbox in Ubuntu
  2. VMSetError: VirtualBox can’t enable the AMD-V extension
  3. Specific Vagrantfile

[!IMPORTANT]

In repositories will be defined some Vagrantfile for two type K8s for base and ceph, for specific the Vagrantfile you should specific them via environment variables. Explore more at: StackOverFlow - Specify Vagrantfile path explicity, if not plugin

   # Run as usual for base version (Default: Vagrantfile)
   vagrant up name-of-your-machine

   # Run specific Vagrantfile for CEPH version (Example: Vagrantfile.ceph)
   VAGRANT_VAGRANTFILE=Vagrantfile.ceph vagrant up name-of-your-machine

Kubewekend Major Session πŸš„πŸš„πŸš„

Kubewekend Session 1: Use Vargrant to configuration the VM with provider

[!NOTE]

This lab is take the topic around play and practice with vagrant - the software can help you provide the virtual machine in your host. First step way to setup kubernetes cluster inside your machine, and play with on next session

Read full article about session at Kubewekend Session 1: Build up your host with Vagrant

Kubewekend Session 2: Ansible - To setup and run script and bring up kubernetes cluster on locally, Use kind

[!NOTE]

This lab is practice with ansible the configuration for setup kind cluster inside machine on the previous session

Read full article about session at Kubewekend Session 2: Setup Kind cluster with Ansible

Kubewekend Session 3: Exploring, understanding and provisioning require components inside the kind cluster

[!NOTE]

This session talk about basically architecture and learn more fundamental components inside kubernetes, and what the structure of them inside clusters

Read full article about session at Kubewekend Session 3: Basically about Kubernetes architecture

Kubewekend Session 4: cilium and ebpf - The powerful kernal service of kubewekend cluster

[!NOTE]

This session will talk and learn about eBPF and the especially representation of eBPF are cilium and hubble to become main CNI of Kubewekend and talk about Observability of them

Read full article about session at Kubewekend Session 4: Learn about ebpf with hubble and cilium

Kubewekend Session 5: Build and Operate High Availability (HA) Kubewekend Cluster

[!NOTE]

This session is really pleasant when we talk about how can create HA cluster with kubewekend, learn more the components inside kubernetes and try figure out about network, security, configuration, container runtime and system via this session

Read full article about session at Kubewekend Session 5: Build HA Cluster

Kubewekend Session 6: CSI and Ceph with Kubewekend

[!NOTE]

This session is covered about topic storage inside Kubernetes cluster, how can they work with CSI Architecture and why we need to CSI Driver for handle this stuff. Furthermore, I try to practice with Ceph - one of popular storage opensource for Kubewekend cluster

Read full article about session at Kubewekend 6: CSI and Ceph with Kubewekend

Kubewekend Session 7: Setup new deployment and route traffic to kubewekend cluster

[!NOTE]

This session explores core networking concepts in Kubernetes, guiding you through the setup of new deployments and demonstrating how to expose services for external access using Ingress and the Gateway API. We also delve into External LoadBalancer concepts and the operational nuances of managing them via Cilium NodeIPAM. By the end of this session, you will understand how to bridge the gap between cluster-internal services and external clients using modern, eBPF-powered networking strategies.

Read full article about session at Kubewekend Session 7: Setup new deployment and route traffic to kubewekend cluster

Kubewekend Session 8: Setting Up the Cluster Monitoring Stack with LGTM and Grafana Alloy

[!NOTE]

This session provides the opportunity to deploy the LGTM stack, the comprehensive observability suite from the Grafana ecosystem. You will gain hands-on experience in correlating logs, metrics, traces, and profiling data to achieve deep-level observability within a Kubernetes environment.

Read full article about session at Kubewekend Session 8: Setting Up the Cluster Monitoring Stack with LGTM and Grafana Alloy

Kubewekend Extra Session 🚒🚒🚒

Kubewekend Session Extra 1: Longhorn and the story about NFS in Kubernetes

[!NOTE]

This lab is try to take you to journey to learn about new CSI for Kubernetes, Longhorn and deliver you to new method to handle transfer large file via network by NFS protocol. I also provide more information about iSCSI, nfs-ganesha and technique rdma

Read full article about session at Kubewekend Session Extra 1: Longhorn and the story about NFS in Kubernetes

Kubewekend Session Extra 2: Rebuild Cluster with RKE2 or K3S

[!NOTE]

This article aims to provide you with insights into alternatives for self-hosting a full Kubernetes cluster. Both K3s and RKE2 are strong contenders worth considering to guide your decision. Focusing on the self-hosted approach with RKE2, I want to share more about my experiences working with it over the past four months.

Read full article about session at Kubewekend Session Extra 2: Rebuild Cluster with RKE2 or K3S

Kubewekend Session Extra 3: RKE2 and The Nightmare with Network and CoreDNS

[!NOTE]

This article is my story about wrestling with networking in Kubernetes. I’ll cover the frustrating problems that arise when your pods can’t communicate with services, CoreDNS fails to resolve domains, and the tough issues involving CNI and the ChecksumTX of network interfaces in Kubernetes.

Read full article about session at Kubewekend Session Extra 3: RKE2 and The Nightmare with Network and CoreDNS

Kubewekend Session Extra 4: Kind and Sandbox environment for GitLab CI

[!NOTE]

This article shares my experience setting up a sandbox environment with Kind to adapt new Kubernetes environments within CI/CD pipelines. I’ll provide several ideas for running both CPU and GPU applications, demonstrating their behavior specifically within GitLab CI.

Read full article about session at Kubewekend Session Extra 4: Kind and Sandbox environment for GitLab CI

Kubewekend Session Extra 5: Learn about the security model in Kubernetes

[!NOTE]

This session covers the Kubernetes API security pipeline across its primary phases (AuthN, AuthZ, and Admission Controllers). It also explores broader Kubernetes security concepts for securing resources, networks, and workloads, while demonstrating how to deploy and experiment with Kyverno as a policy engine to enforce security practices in Kubernetes.

Read full article about session at Kubewekend Session Extra 5: Learn about the security model in Kubernetes
